The Story
OVERVIEW
- MFT Mount Cinema Lens
- Aperture Range: T2.2 to T22
- Multilayer Coating
- Manual Focus Design
The Meike 35mm T2.2 Manual Focus Cinema Lens (MFT Mount) from Meike is a versatile lens suitable for high-resolution cine cameras. The T2.2 maximum aperture enables working in difficult lighting conditions and offers increased control over depth of field. In harsh lighting conditions, a multilayer coating is also used to reduce flare and ghosting for greater contrast and color accuracy. This manual focus lens permits working with subjects as close as 9.8" away, and a printed focusing scale aids with prefocusing techniques.
The Meike 35mm T/2.2 is entirely made out of metal, and the focus/aperture rings have standard 0.8 mod/32 pitch gears. The focus ring has a focus throw of 270 degrees, so you shouldn’t have any issues when using it with a manual/wireless follow focus. In terms of lens design, there are ten elements in eight groups for a total weight of around 1.45 lbs/660 grams. The minimum focus distance is 0.51m.
The lens is relatively compact, with a total length of only 80mm. If you want, you can screw filters directly to the front element that features a diameter of 77mm.
SPECS
| Focus | Manual Focus |
| Aperture | Manual Aperture |
| Focal Length | 35mm |
| T-Stop Range | T2.2 - T22 |
| Focus Rotations | 270° |
| Min. Focusing Distance | 0.51m / 1.67ft |
| Lens Construction | 8 groups 10 element |
| Filter Size | 77mm |
| 4/3" Angle of View | horizontal: 29.7 °/ vertical: 22.4 °/ diagonal: 37 ° |
| Operating Temperature | -10 ~+50 |
| Weight | 1.5lbs |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
OVERVIEW
- MFT Mount Cinema Lens
- Aperture Range: T2.2 to T22
- Multilayer Coating
- Manual Focus Design
The Meike 35mm T2.2 Manual Focus Cinema Lens (MFT Mount) from Meike is a versatile lens suitable for high-resolution cine cameras. The T2.2 maximum aperture enables working in difficult lighting conditions and offers increased control over depth of field. In harsh lighting conditions, a multilayer coating is also used to reduce flare and ghosting for greater contrast and color accuracy. This manual focus lens permits working with subjects as close as 9.8" away, and a printed focusing scale aids with prefocusing techniques.
The Meike 35mm T/2.2 is entirely made out of metal, and the focus/aperture rings have standard 0.8 mod/32 pitch gears. The focus ring has a focus throw of 270 degrees, so you shouldn’t have any issues when using it with a manual/wireless follow focus. In terms of lens design, there are ten elements in eight groups for a total weight of around 1.45 lbs/660 grams. The minimum focus distance is 0.51m.
The lens is relatively compact, with a total length of only 80mm. If you want, you can screw filters directly to the front element that features a diameter of 77mm.
SPECS
| Focus | Manual Focus |
| Aperture | Manual Aperture |
| Focal Length | 35mm |
| T-Stop Range | T2.2 - T22 |
| Focus Rotations | 270° |
| Min. Focusing Distance | 0.51m / 1.67ft |
| Lens Construction | 8 groups 10 element |
| Filter Size | 77mm |
| 4/3" Angle of View | horizontal: 29.7 °/ vertical: 22.4 °/ diagonal: 37 ° |
| Operating Temperature | -10 ~+50 |
| Weight | 1.5lbs |
